Supermicro's X10 Broadwell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.
- General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.com
- Brand Name
- Supermicro
- Product Line
- SuperServer
- Packaged Quantity
- 10
- Package Type
- Bulk
- Product Type
- Server Barebone System
- Warranty
- Limited Warranty
- 3 Year
- Processor
- Number of Processors Supported
- 2
- Processor Socket
- Socket R3 LGA-2011
- Processor Supported
- Xeon
- 64-bit Processing
- Yes
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- C612
- Memory
- Maximum Memory Supported
- 1 TB
- Memory Technology
- DDR4 SDRAM
- Memory Standard
- DDR4-2400/PC4-19200
- Total Number of Memory Slots
- 8
- Controllers
- Controller Type
- Serial ATA/600
- RAID Supported
- Yes
- Display & Graphics
- Graphics Controller Model
- AST2400
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Fast Ethernet
- I/O Expansions
- Number of Total Expansion Bays
- 4
- Number of 3.5" Bays
- 4
- Total Number of Expansion Slots
- 1
- Number of PCI Express x8 Slots
- 1
- Interfaces/Ports
- Total Number of USB Ports
- 9
- Number of USB 3.0 Ports
- 2
- Number of SATA Interfaces
- 4
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Number of Power Supplies Installed
- 2
- Maximum Power Supply Wattage
- 400 W
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Rack-mountable
- Rack Height
- 1U
- Height
- 1.7"
- Width
- 17.2"
- Depth
- 19.8"
- Miscellaneous
- Package Contents
- SuperServer 6018R-MTR (Black)
- 1 x Super X10DRL-i Motherboard
- 1 x 1U Chassis
- 1 x 4-port 1U TQ backplane (W/ enclosure management), support up to 4x 3.5-inch SAS/SATA HDD
- 1 x SATA,INT,ROUND,SET OF 4,ST-RA 56/45.5/35/23CM,26AWG
- 1 x CBL,SGPIO,2X4F TO 2X4F,P2.54,ROUND CABLE,40CM,28AWG
- 1 x SC813M,SC113M, DP X9DRL-EF/ X9DRL-7F/ X10DRL-i, X9/X10 mylar air shroud, 12
- 1 x 1 SYS-6018R-MT/MTR, QRG,HF,RoHS/REACH
- 1 x 1 RSC-RR1U-E8 Riser Card
- 2 x 1U Passive Custom CPU Heat Sink for X9DRL, X10DRL Related Systems
- 2 x 1U 400W Redundant Short Depth Power Supply
- 4 x 40x40x28 mm, 17.5K RPM, SC813MTS Middle Cooling Fan,RoHS/REACH,PBF
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
