• General Information
• • Manufacturer
  • Rocstor
  • Manufacturer Website Address
  • http://www.rocstor.com
  • Brand Name
  • Rocstor
  • Product Line
  • TrueReach
  • Product Type
  • KVM Extender Transmitter/Receiver

Out-of-the-Box Dual Display Power

The TrueReach® TR23 delivers 4096×2160 @ 60Hz Ultra HD video wirelessly with near-zero latency. This kit includes one transmitter and two receivers, giving you instant flexibility to power two displays or rooms simultaneously without purchasing extra hardware. Powered by ipcolor STREAM technology, it ensures uncompromised clarity and responsiveness - perfect for corporate, education, and enterprise AV installations.

Visual suggestion: Meeting room setup showing TR23 TX feeding two RX units powering dual displays.

Wireless Freedom and Scalable Flexibility

The TR23 transmits HDMI signals wirelessly up to 164ft (50m) in a one-to-one configuration, or 98ft (30m) when both included receivers are active. The system can be expanded to support up to four receivers total by adding optional units. Intelligent scaling guarantees reliable performance:

1 to 1 ? 164ft (50m)

1 to 2 ? 98ft (30m) (included configuration)

1 to 3 ? 66ft (20m)

1 to 4 ? 49ft (15m)

Visual suggestion: Simple diagram showing 1 TX ? 2 RX included, expandable to 4.

Complete Wireless Control

With two USB 2.0 ports per receiver, the TR23 allows remote connection of keyboards, mice, webcams, storage, and even touchscreens. Its KVM passback functionality makes controlling the host PC seamless from any connected display. Added features like IR pass-through, RS232 support, and HDMI loop-out on the transmitter make it a full professional AV solution.

Visual suggestion: Receiver connected to a touchscreen monitor and USB devices.

Built for Demanding Environments

Designed with enterprise reliability in mind, the TrueReach® TR23 operates on the 5G wireless band for strong anti-interference performance. SSID pairing and channel switching eliminate conflicts in multi-system environments. With lightning, surge, and ESD protection, plus a rugged black metal housing, the TR23 is engineered for stable 24/7 operation in mission-critical spaces.

Visual suggestion: Close-up product shot showing rugged housing with subtle lighting effect.

Key Features

• Wireless HDMI extension up to 164ft (50m) one-to-one
• Kit includes 1x HDMI Transmitter (TX) and 2x HDMI Receivers (RX)
• Expandable up to 4 receivers with optional add-ons
• Resolutions up to 4096×2160@60Hz (4K Ultra HD)
• KVM support with (2) USB 2.0 ports per receiver - keyboard, mouse, webcam, storage, touchscreen
• HDMI loop-out for local monitoring
• One-to-Many wireless support: up to 4 receivers
