Expand your network's bandwidth and reduce digital bottlenecks with TRENDnet's Unmanaged 2.5G Switches. These 2.5G network switches come equipped with 2.5GBASE-T RJ-45 ports that provide ultra-fast speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. Each high-speed 2.5G switch features a durable metal enclosure and can be mounted to the wall for setup flexibility. The fanless design lowers energy consumption and eliminates operating noise. The sturdy metal housing and included rackmount brackets are well-suited for wall mount or 19? 1U rack installations. TRENDnet's reliable 2.5G switches are cost-effective solutions to increase your network's throughput.
- DEVICE INTERFACE: 16 x 2.5G RJ-45 (10Mbps/100Mbps/1Gbps/ 2.5Gbps); LED indicators
- LIFETIME PROTECTION -We stand by the quality of our products. The TEG-S3160 16-Port Unmanaged 2.5G Desktop Network Ethernet Switch is secured with Lifetime Manufacturer Protection from TRENDnet. (U.S. and Canada Only)
- NDAA + TAA COMPLIANT: With our NDAA and TAA compliant network switches, you can plan and install networking solutions that Government customers demand today (U.S. and Canada Only)
- 2.5G PORTS: The 16 Port network switch is equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling.
- SWITCHING CAPACITY: The unmanaged switch is equipped with a 80Gbps Switching Capacity
- WALL MOUNTABLE: The 2.5G unmanaged switch features a durable metal housing with a convenient wall mountable design for greater installation flexibility.
- FANLESS DESIGN: The fanless design lowers energy consumption and eliminates distracting operating noise.
- General Information
- Manufacturer
- TRENDnet
- Manufacturer Website Address
- http://www.trendnet.com
- Brand Name
- TRENDnet
- Product Type
- Ethernet Switch
- Warranty
- Limited Warranty
- Lifetime
- Technical Information
- Features
- Fanless
- Interfaces/Ports
- Total Number of Network Ports
- 16
- Network (RJ-45)
- Yes
- Media & Performance
- Media Type Supported
- Twisted Pair
- Ethernet Technology
- 2.5 Gigabit Ethernet
- Network Technology
- 2.5GBase-T
- Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3z
- IEEE 802.3ab
- IEEE 802.3az
- IEEE 802.3bz
- Management & Protocols
- Manageable
- No
- Reliability
- MTBF
- 223000 Hour
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 47 Hz
- 63 Hz
- Power Source
- AC
- Power Consumption
- 7.26 W
- Physical Characteristics
- Form Factor
- Rack-mountable
- Wall Mountable
- Desktop
- Height
- 1.1"
- Width
- 5"
- Length
- 11.3"
- Weight (Approximate)
- 2.16 lb
- Miscellaneous
- Package Contents
- 16-Port Unmanaged 2.5G Desktop Switch
- Quick Installation Guide
- Rackmount Kit
- Power Adapter (12V DC, 3A)
- Application/Usage
- Network
