- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com
- Brand Name
- TP-Link
- Product Line
- Omada
- Product Type
- Ethernet Switch
- Technical Information
- Features
- DHCP Snooping
- Zero-Touch Provisioning (ZTP)
- Energy Efficient
- Interfaces/Ports
- Total Number of Network Ports
- 48
- Uplink Port
- Yes
- Stack Port
- Yes
- Port/Expansion Slot Details
- 8 x Gigabit Ethernet PoE++
- 40 x Gigabit Ethernet PoE+
- 4 x 10 Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- Gigabit Ethernet
- 10 Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- 10GBase-X
- I/O Expansions
- Total Number of Expansion Slots
- 4
- Expansion Slot Type
- SFP+
- Number of SFP+ Slots
- 4
- Network & Communication
- Layer Supported
- 3
- Networking Standards
- IEEE 802.1x
- IEEE 802.3x
- IEEE 802.3ad
- IEEE 802.1Q
- IEEE 802.1D
- IEEE 802.1w
- IEEE 802.1s
- IEEE 802.1ab
- IEEE 802.1p
- IEEE 802.3az
- IEEE 802.3af
- IEEE 802.3at
- Management & Protocols
- Manageable
- Yes
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 770 W
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- Power Supply
- AC
- PoE++
- PoE+
- Power Consumption
- 942.70 W
- Physical Characteristics
- Product Material
- Metal
- Form Factor
- Rack-mountable
- Height
- 1.70" (43.18 mm)
- Width
- 17.30" (439.42 mm)
- Depth
- 13" (330.20 mm)
- Miscellaneous
- Application/Usage
- Network
- Wireless Access Point
- Business
- Outdoor
- Security
- IP Phone
- Camera
- Surveillance
