- General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.com
- Brand Name
- Supermicro
- Packaged Quantity
- 1
- Package Type
- Retail
- Product Type
- Workstation Motherboard
UP Xeon® Motherboards - Socket H4 (LGA 1151)
Xeon® E-2100 Boards / Socket H4 (LGA 1151)
Supermicro's new X11SCA workstation motherboard comes in a standard ATX form factor packed with features and expandability options including 4k video support. Optimized for the latest Xeon E processors, this platform supports up to 64GB of either ECC or non-ECC DDR4-2666 memory, triple displays with DisplayPort 1.2, HDMI 2.0, DVI-D; dual M.2, U.2, dual GbE LAN ports, and USB 3.1 Gen 2. In addition, there is a front panel USB-C header on the X11SCA motherboard with different versions to add either gigabit wireless 802.11ac with Bluetooth 5.0 (X11SCA-W) or Supermicro IPMI 2.0 with an additional VGA port (X11SCA-F).
- Processor & Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- C246
- Total Processor Supported
- 1
- Processor Socket
- Socket H4 LGA-1151
- Processor Supported
- Celeron
- Pentium
- Core i3
- Xeon
- Memory
- Number of Memory Slots
- 4
- Memory Form Factor
- DIMM
- UDIMM
- Maximum Memory Supported
- 64 GB
- Memory Technology
- DDR4 SDRAM
- Memory Speed Supported
- 2666 MHz
- 2400 MHz
- 2133 MHz
- 1866 MHz
- 1600 MHz
- I/O Controller
- Controller Type
- Serial ATA/600
- RAID Supported
- Yes
- RAID Levels
- 0
- 1
- 5
- 10
- Video
- Onboard Video
- On-board Video Chipset
- Graphics Controller Manufacturer
- ASPEED
- Graphics Controller Model
- AST2500
- Audio
- Audio Channels
- 7.1
- Network & Communication
- Gigabit Ethernet
- Yes
- I/O Expansions
- Total Number of Expansion Slots
- 3.0
- Total Number of PCI Express Slots
- 3
- Number of PCI Express x8 Slots
- 2
- Number of PCI Express x16 Slots
- 1
- Interfaces/Ports
- Total Number of USB Ports
- 6
- Number of USB 3.1 Ports
- 6
- VGA
- Yes
- DisplayPort
- Yes
- DVI
- Yes
- Onboard Interfaces
- Number of SATA Interfaces
- 5
- Number of M.2 Interfaces
- 1
- Total Number of Onboard USB Ports
- 9
- Number of Onboard USB 3.1 Ports
- 2
- Physical Characteristics
- Form Factor
- Micro ATX
- Width
- 9.6"
- Depth
- 9.6"
