- General Information
- Manufacturer
- Sharp
- Manufacturer Website Address
- http://www.sharp-nec-displays.com/
- Brand Name
- NEC Display
- Product Line
- MultiSync
- Product Series
- M
- Product Type
- Digital Signage Display
Create pixel-perfect imagery with the high-end panel quality of the fully professional NEC M Series large format displays. By focusing on customer needs while also offering professional reliability, the M series displays give customers a digital signage display lineup without all the costs. The M series can support both landscape and portrait orientations while also allowing the modularity possibilities to customize their needs dependent on their application and use. The new series contain a full metal mechanical chassis, allowing for a more robust design necessary for commercial applications while maintaining the attractive aesthetics that allow the focus of onlookers to be on what matters - the message. Simple and targeted connectivity options allow customers to have the up-to-date options that they need while not having to overpay for excess and unused interfaces. The NEC M series boasts 500 cd/m² brightness which is ideal for a majority of digital signage applications in corporate, higher education, restaurant, retail and grocery store environments when the focus should be on the message, not the budget.
- 4K UHD native resolution allows for crystal clear imagery and messaging that become more vivid and lifelike than ever before!
- Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
- Accepts Intel® Smart Display Module Small or Large allowing for sleek all-in-one intelligence and interoperability in a small form factor setting by accepting Intel processor-based products and other peripherals directly into the displays
- Raspberry Pi Compute Module 4 allows for future proof expansion and NEC Mediaplayer support (Q2 2021)
- Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C
- 500 cd/m2 brightness and HDR compatibilty will capture the attention of audience in almost any situation
- Integrated Media Player allows for audio, video or image playback via USB
- Failover Capabilities with full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails
- Integrated Ambient Light Sensor allows the display to autmatically adjust its luminance based on external brightness conditions
- Energy Star 8.0 Certified Product
- Full 3 year commercial warranty to allow for peace of mind and protection of your investment
- NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations
- Cisco Certified Display
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Bezel Width (Bottom)
- 0.61"
- Bezel Width (Top)
- 0.43"
- Bezel Width (Left)
- 0.43"
- Bezel Width (Right)
- 0.43"
- Display & Graphics
- Screen Size
- 49"
- Display Screen Type
- LCD
- Display Resolution
- 3840 x 2160
- High Dynamic Range (HDR)
- Yes
- High Dynamic Range (HDR) Type
- HDR10
- Response Time
- 8 ms
- Pixel Pitch
- 11 mil
- Aspect Ratio
- 16:9
- Backlight Technology
- Edge LED
- Curved Screen
- No
- Audio
- Speakers
- Yes
- Video
- Scan Format
- 2160p
- Standard Refresh Rate
- 60 Hz
- Color Depth
- 8-bit+FRC
- Brightness
- 500 Nit
- Network & Communication
- Ethernet
- Yes
- Interfaces/Ports
- USB
- Yes
- HDMI
- Yes
- DisplayPort
- Yes
- Serial
- Yes
- Number of USB 2.0 Ports
- 1
- Number of HDMI Inputs
- 2
- Number of DisplayPorts
- 1
- Power Description
- Input Voltage
- 230 V AC
- Physical Characteristics
- VESA Mount Standard
- 300 x 300
- Mount Type
- Wall Mountable
- Table Mount
- Height
- 25.1"
- Width
- 43.4"
- Depth
- 2.4"
- Weight (Approximate)
- 48.10 lb
- Miscellaneous
- Package Contents
- 49" Ultra High Definition Professional Display
- 3m Power cord
- 2.0m HDMI cable
- Wireless remote control
- Batteries
- Setup Guide
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Energy Efficiency Certification
- ENERGY STAR 8.0
- Country of Origin
- China
