Create pixel perfect imagery with the high-end panel quality of the new fully commercial Sharp PN-M Series large format displays. By implementing premium features and focusing on creating impressionable digital signage experiences, the PN-M series gives customers an elite display option with its one-of-a-kind and proprietary SpectraView Engine capabilities, these displays offer out-of-the-box factory panel calibration, allowing for consistent visuals out of the box. On top of that, these products allow customers the modularity capabilities to customize their product based on their needs and application. The new series contain a full metal mechanical chassis, allowing for a more robust design necessary for commercial applications while maintaining the attractive aesthetics that allow the focus of onlookers to be on what matters - the message. Robust connectivity interface allows customers to have up-to-date connectivity options while also allowing for enhanced daisy chain capabilities when tying displays together for video or control signal distribution. The Sharp PN-M series boasts 550 cd/m2 brightness which is ideal for a majority of high end digital signage applications in restaurants, command and control, retail, healthcare and corporate environments when high-end and feature rich displays are necessary to convey important messaging.
- Industrial-strength, premium-grade panel with additional thermal protection, internal temperature sensors with self-diagnostics and fan-based technology, allow for 24/7 operation
- 4K UHD native resolution allows for crystal clear imagery and messaging that become more vivid and lifelike than ever before!
- Integrated USB-C input with DP-Alt Mode, 65W Power Delivery and Hub functionality allow for more streamlined operations when using as a presentation type of device
- Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
- Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C
- LAN Daisy Chain passes RS-232C, TCP-IP and IR signal to easily control groups of displays without having to run extra cable
- 550 cd/m2 brightness with high haze panel will capture the attention of audience in almost any situation
- Enhanced Daisy Chain Capabilities through both HDMI and DisplayPort Out Connections passing any digital input into the display
- Failover Capabilities with full Input Change functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails
- Energy Star 8.0 Certified Product
- General Information
- Manufacturer
- Sharp
- Manufacturer Website Address
- http://www.sharp-nec-displays.com/
- Brand Name
- Sharp NEC Display
- Product Line
- MultiSync
- Product Series
- PN-M
- Product Type
- Digital Signage Display
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Bezel Width (Bottom)
- 0.56"
- Bezel Width (Top)
- 0.56"
- Bezel Width (Left)
- 0.56"
- Bezel Width (Right)
- 0.56"
- Ingress Protection (IP) Rating
- IP5X
- IP2X
- Panel Technology
- In-plane Switching (IPS) Technology
- Operation Hours
- 24 Hours/7 Days
- Display & Graphics
- Number of Screens
- 1
- Viewable Screen Size
- 86"
- Screen Size Class
- 86"
- Display Screen Type
- LCD
- Display Resolution
- 3840 x 2160
- Response Time
- 8 ms
- Pixel Pitch
- 19.4 mil
- Aspect Ratio
- 16:9
- Backlight Technology
- Direct LED
- Orientation
- Landscape/Portrait
- Video
- Scan Format
- 2160p
- Native Contrast Ratio
- 1,200:1
- Color Depth
- 10-bit
- Brightness
- 550 Nit
- Network & Communication
- Ethernet
- Yes
- Interfaces/Ports
- USB
- Yes
- HDMI
- Yes
- DisplayPort
- Yes
- Serial
- Yes
- Number of HDMI Inputs
- 2
- Number of HDMI Outputs
- 1
- Number of DisplayPorts
- 2
- USB Type-C
- Yes
- DisplayPort Output
- Yes
- RS-232C Input
- Yes
- Number of Network (RJ-45) Ports
- 3
- Number of HDMI 2.0 Ports
- 3
- Number of DisplayPort Outputs
- 1
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Environmental Conditions
- Minimum Storage Temperature
- -4°F (-20°C)
- Maximum Storage Temperature
- 140°F (60°C)
- Minimum Operating Humidity
- 20%
- Maximum Operating Humidity
- 80%
- Minimum Storage Humidity
- 10%
- Maximum Storage Humidity
- 80%
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Bezel Color
- Black
- VESA Mount Standard
- 400 x 400
- Mount Type
- Wall Mountable
- Mount Surface
- Wall
- Height
- 43.3"
- Width
- 75.9"
- Depth
- 3.3"
- Weight (Approximate)
- 103.62 lb
- Housing Material
- Metal
- Miscellaneous
- Package Contents
- 86" Ultra High Definition Professional Display
- 3m Power cord
- 2.0m HDMI cable
- IR Remote Control
- Batteries
- Application/Usage
- Meeting Room
- Public Space
- Energy Star
- Yes
- Energy Efficiency Certification
- ENERGY STAR 8.0
