Precision performance for critical applications
When reliability, security, and exceptional visual performance are mandatory, the Sharp MultiSync® P6 Series delivers with precision and resilience. Despite its slim profile, the P6 Series is endorsed for use in heavy traffic spaces with a durable all-metal chassis that complies to the strictest fire safety standards. Building on NEC's trusted heritage, the next generation Sharp P6 Series is designed for longevity and integration flexibility. Its modular architecture supports custom computing options by Intel® SDM or Raspberry Pi, and flexible connectivity including AVoverIP for versatile deployments. Native video daisy chaining via HDMI and DisplayPort enables content to be easily cloned or expanded across multiple displays. Compatibility with leading platforms such as Crestron, Cisco Webex, and Q-Sys enhances its future-proof appeal, while 802.1x LAN support safeguards robust security against cyber threats.
Benefits
- Enhanced imaging precision - when brand consistency and corporate identity are important, NEC's SpectraView Engine provides full control over colour, gamma, and uniformity for accurate and impactful content.
- Unhindered readability - a high-haze panel reduces glare from windows and ambient light, keeping signage content and presentations clear for uninterrupted viewing in any environment
- Security assured - 802.2x support over LAN enables high-level security for corporate networks, giving peace of mind for IT teams and enterprise environments.
- Mission-critical performance - with 700 cd/m² brightness, long-life components and robust flame-resistant metal chassis, the P6 series is engineered to deliver lasting clarity and durability in challenging environments without the need for bulky housings.
- Trusted integration - full compatibility with major AV ecosystems, including Crestron XiO Cloud and NVX, Q-Sys, Cisco Webex, Matrox IPMX, and CMS solutions, ensures seamless setup and scalability.
- General Information
- Manufacturer
- Sharp Electronics
- Manufacturer Website Address
- http://www.sharpusa.com
- Brand Name
- Sharp
- Product Line
- MultiSync
- Product Series
- P6
- Product Type
- Digital Signage Display
- Technical Information
- Bezel Width (Bottom)
- 0.55" (13.90 mm)
- Bezel Width (Top)
- 0.43" (10.90 mm)
- Bezel Width (Left)
- 0.43" (10.90 mm)
- Bezel Width (Right)
- 0.43" (10.90 mm)
- HDCP Version
- 2.2
- Ingress Protection (IP) Rating
- IP5X
- IP2X
- Panel Technology
- Vertical Alignment (VA)
- Operation Hours
- 24 Hours/7 Days
- Horizontal Frequency
- 15kHz to 135kHz
- Vertical Frequency
- 23Hz to 76Hz
- Display & Graphics
- Number of Screens
- 1
- Viewable Screen Size
- 50" (1270 mm)
- Screen Size Class
- 49.50" (1257.30 mm)
- Display Screen Type
- LCD
- Display Resolution
- 3840 x 2160
- Response Time
- 8 ms
- Pixel Pitch
- 11.22 mil (0.28 mm)
- Aspect Ratio
- 16:9
- Backlight Technology
- Direct LED
- Orientation
- Face-up/Landscape/Portrait/Face-down
- Video
- Scan Format
- 2160p
- Native Contrast Ratio
- 4,000:1
- Color Depth
- 10-bit
- Brightness
- 700 cd/m²
- Color Gamut
- 86% DCI
- Network & Communication
- Ethernet
- Yes
- Interfaces/Ports
- USB
- Yes
- HDMI
- Yes
- DisplayPort
- Yes
- Serial
- Yes
- Number of HDMI Inputs
- 2
- Number of HDMI Outputs
- 1
- Number of DisplayPorts
- 2
- USB Type-C
- Yes
- DisplayPort Output
- Yes
- RS-232C Input
- Yes
- Digital Audio Optical Output
- Yes
- Number of Network (RJ-45) Ports
- 2
- Number of Audio Line Out
- 1
- Number of HDMI 2.0 Ports
- 2
- Number of DisplayPort Outputs
- 1
- DisplayPort In
- Yes
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Environmental Conditions
- Minimum Operating Temperature
- 32°F (0°C)
- Maximum Operating Temperature
- 104°F (40°C)
- Minimum Storage Temperature
- -4°F (-20°C)
- Maximum Storage Temperature
- 140°F (60°C)
- Minimum Operating Humidity
- 20%
- Maximum Operating Humidity
- 80%
- Minimum Storage Humidity
- 10%
- Maximum Storage Humidity
- 80%
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Bezel Color
- Black
- VESA Mount Standard
- 300 x 300
- Mount Type
- Wall Mountable
- Table Mount
- Height
- 25.40" (645.20 mm)
- Width
- 44.16" (1121.60 mm)
- Depth
- 2.62" (66.50 mm)
- Weight (Approximate)
- 39.68 lb (18000 g)
- Housing Material
- Metal
- Miscellaneous
- Application/Usage
- Commercial
- Restaurant
- Control Room
- Retail
- Healthcare
- Corporate
- Energy Star
- Yes
- Environmental Compliance
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Restriction of Hazardous Substances (RoHS)
- Energy Efficiency Certification
- ENERGY STAR 8.0
