- General Information
- Manufacturer
- Para Systems, Inc
- Manufacturer Website Address
- http://www.minutemanups.com
- Brand Name
- Minuteman
- Product Series
- EXR
- Product Type
- Line-interactive UPS
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
Limited warranty - electrical components and functions - 3 years ¦ Limited warranty - batteries - 3 years
- Technical Information
- Plug/Connector Type
- NEMA L5-30P
- Receptacle Type
- NEMA L5-30R
- NEMA 5-20R
- Receptacle Detail
- 1 x NEMA L5-30R
- 6 x NEMA 5-20R
- Dataline Protection
- RJ-45
- Phase
- Single Phase
- Application/Usage
- Network Device
- Electronic Equipment
- Power Description
- Load Capacity (VA)
- 3000 VA
- Load Capacity (Watt)
- 2700 W
- Input Voltage
- 120 V AC
- Input Voltage Range
- 80 V AC - 164 V AC
- Output Voltage
- 120 V AC
- Input Frequency
- 60 Hz
- Waveform Type
- Sine Wave
- Surge Energy Rating
- 1000 J
- Display & Graphics
- Display
- LCD
- Management
- Network Management
- SNMP
- Interfaces/Ports
- Serial Port
- Yes
- Network (RJ-45)
- Yes
- USB
- Yes
- EPO Port
- Yes
- Battery Information
- Battery Characteristics
- Sealed, Non-spillable, Maintenance-free, Valve-regulated
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 2.50 Minute
- Backup/Run Time (Half Load)
- 10 Minute
- Typical Battery Recharge Time
- 8 Hour
- Hot Swappable
- Yes
- Environmental Conditions
- Maximum Operating Temperature
- 104°F (40°C)
- Operating Humidity
- 0% - 95%
- Physical Characteristics
- Height
- 3.5"
- Width
- 19"
- Depth
- 23.6"
- Rack Height
- 2U
- Form Factor
- Tower/Rack/Wall Mountable
- Weight (Approximate)
- 77.60 lb
- Miscellaneous
- Software Included
- Minuteman SentryHD
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS) 2
