- General Information
- Manufacturer
- Lenovo Group Limited
- Manufacturer Website Address
- http://www.lenovo.com/us/en/
- Brand Name
- Lenovo
- Product Line
- ThinkSystem
- Product Series
- SR650 V2
- Product Type
- Server
The Lenovo ThinkSystem SR650 V2 is an ideal 2-socket 2U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR650 V2 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD).
- Processor
- Number of Processors Supported
- 2
- Number of Processors Installed
- 1
- Processor Manufacturer
- Intel
- Processor Type
- Xeon Gold
- Processor Generation
- 3rd Gen
- Processor Model
- 5320
- Processor Core
- Hexacosa-core (26 Core)
- Processor Speed
- 2.20 GHz
- Cache
- 39 MB
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- C621A
- Memory
- Standard Memory
- 32 GB
- Memory Technology
- TruDDR4
- Memory Clock Speed
- 3.20 GHz
- Error Checking
- ECC
- Total Number of Memory Slots
- 32.0
- Number of Occupied Memory Slots
- 1
- Intel Optane Memory Ready
- Yes
- Signal Processing
- Registered (Buffered)
- Storage
- Optical Drive Type
- No
- Controllers
- Controller Type
- Serial ATA/600
- 12Gb/s SAS
- Display & Graphics
- Graphics Controller Manufacturer
- Matrox
- Graphics Controller Model
- G200
- Graphics Memory Capacity
- 16 MB
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Interfaces/Ports
- Total Number of USB Ports
- 6
- Number of USB 2.0 Ports
- 1
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 1
- VGA
- Yes
- Number of VGA Ports
- 2
- Remote Management
- Yes
- Remote Management Controller
- XCC Enterprise
- Operating System
- Operating System Supported
- Red Hat Enterprise Linux 9.1
- SUSE Linux Enterprise Server 15 SP4
- Ubuntu 18.04 LTS
- Ubuntu 20.04 LTS
- Ubuntu 22.04 LTS
- Windows Server 2019
- Windows Server 2022
- Red Hat Enterprise Linux 7.9
- Red Hat Enterprise Linux 8.2
- Red Hat Enterprise Linux 8.3
- Red Hat Enterprise Linux 8.4
- Red Hat Enterprise Linux 8.5
- SUSE Linux Enterprise Server 12 SP5
- SUSE Linux Enterprise Server 15 SP2
- SUSE Linux Enterprise Server 15 SP3
- Red Hat Enterprise Linux 8.6
- Red Hat Enterprise Linux 8.7
- Red Hat Enterprise Linux 9.0
- Operating System
- No
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 1
- Plug/Connector Type
- C13
- Maximum Power Supply Wattage
- 750 W
- Hot Swappable Power Supply
- Yes
- Power Source
- Power Supply
- Physical Characteristics
- Form Factor
- Rack
- Rack Height
- 2U
- Height
- 3.4"
- Width
- 17.5"
- Depth
- 30.1"
- Weight (Approximate)
- 85.54 lb
- Miscellaneous
- Security Features
- Chassis Intrusion Switch
- Power-on Password
- Administrator's Password
- Trusted Platform Module (TPM), supporting TPM 2.0
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Environmental Certification
- China Environmental Labeling Program (CELP)
- Electronic Product Environmental Assessment Tool Bronze (EPEAT Bronze)
- GREENGUARD
- Energy Efficiency Certification
- China Energy Conservation Program (CECP)
- ENERGY STAR 3.0
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
