- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Smart-UPS
- Product Type
- Line-interactive UPS
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1920VA line interactive tower UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-20P input, 8 NEMA 5-15R and 2 NEMA 5-20R outlets. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 3-year warranty, and built-in lead-acid battery has a 2-year warranty. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
- 3 years repair or replace (excluding battery) and 2 years for battery, optional on-site warranties available, optional extended warranties available
- Directly Connected Equipment Guarantee
- $150000 Lifetime
- Technical Information
- Plug/Connector Type
- NEMA 5-20P
- Receptacle Type
- NEMA 5-20P
- Receptacle Detail
- 2 x NEMA 5-20R
- 8 x NEMA 5-15R
- Number of Battery & Surge Outlets
- 10
- Cord Length
- 6 ft
- Transfer Time
- 10 ms
- Application/Usage
- Server
- POS Terminal
- Router
- Switch
- Network Hub
- Network Device
- Power Description
- Load Capacity (VA)
- 1920 VA
- Load Capacity (Watt)
- 1980 W
- Input Voltage
- 120 V
- Input Voltage Range
- 75 V AC - 154 V AC
- Output Voltage
- 120 V AC
- Waveform Type
- Sine Wave
- Surge Energy Rating
- 530 J
- Management
- Network Management
- SmartConnect
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Battery Information
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 10.10 Minute
- Typical Battery Recharge Time
- 3 Hour
- Hot Swappable
- Yes
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Height
- 17.1"
- Width
- 7.7"
- Depth
- 21.4"
- Rack Height
- 2U
- Form Factor
- Tower
- Mounting Location
- Front
- Weight (Approximate)
- 112.24 lb
- Miscellaneous
- Package Contents
- Smart-UPS SMT2200C 2.2KVA Tower UPS
- Smart UPS signalling RS-232 cable
- USB cable
- Certifications & Standards
- cULus|ENERGY STAR V2.0 (USA)
- Software Included
- Powerchute Serial Edition
- Energy Star
- Yes
- Green Premium
- Yes
- Optimized Energy Efficiency
- Yes
- Product Take Back Program
- Yes
- Mercury Free
- Yes
- RoHS Exemption Information
- https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMT2200C_ROHS_DECLARATION&p_FileName=SMT2200CKIT_ROHS_DECLARATION_US.pdf
- REACH Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=465940372&lang=en-us
- EU RoHS Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=465940372&lang=en-us
- Environmental Profile Availability
- https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612029_EN
- End of Life Manual Availability
- https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612029_EN
- California Proposition 65 Warning
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Energy Star URL
- https://www.energystar.gov/products/uninterruptible_power_supplies
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
