- Interfaces/Ports
- Total Number of Network Ports
- 48
- Uplink Port
- Yes
- Port/Expansion Slot Details
- 48 x Gigabit Ethernet Network
- 4 x 10 Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Optical Fiber
- Twisted Pair
- Ethernet Technology
- 10 Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- 10GBase-X
- I/O Expansions
- Total Number of Expansion Slots
- 4.0
- Expansion Slot Type
- SFP+
- Number of SFP+ Slots
- 4
- Network & Communication
- Layer Supported
- 3
- Networking Standards
- IEEE 802.3az
- IEEE 802.3af
- IEEE 802.3at
- IEEE 802.1Q
- IEEE 802.1x
- IEEE 802.3ah
- IEEE 802.1ag
- IEEE 802.1D
- IEEE 802.1w
- IEEE 802.1s
- Management & Protocols
- Manageable
- Yes
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 740 W
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- Power Supply
- Redundant Power Supply Supported
- Yes
- Power Consumption
- 37 W
- Physical Characteristics
- Height
- 1.73" (44 mm)
- Width
- 17.44" (443 mm)
- Depth
- 11.02" (280 mm)
- Weight (Approximate)
- 10.36 lb (4700 g)
- Miscellaneous
- Application/Usage
- Campus
- Network
- IP Phone
- Wireless Access Point
- Security Camera
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
