- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Marketing Information
The new MICA-101 has the same integrated features and ergonomic design as its predecessor, but the new release has been enhanced to provide better imagery, faster storage, and better power, making it even more robust. MICA-101 mobile clinical assistant is suitable for EMR, HER, and Nursing Information Systems (NIS). It is a fanless system that is lightweight, portable and quiet to use, and it streamlines workflow while increasing productivity.
- Product Type
- Tablet
- Warranty
- Limited Warranty
- 2 Year
- Processor
- Processor Type
- Atom
- Processor Model
- Z530
- Processor Speed
- 1.60 GHz
- Processor Core
- Single-core (1 Core)
- Cache
- 512 KB
- Bus Speed
- 533 MHz
- 64-bit Processing
- No
- Hyper-Threading
- Yes
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- US15W
- Memory
- Standard Memory
- 2 GB
- Memory Technology
- DDR2 SDRAM
- Storage
- Solid State Drive Capacity
- 64 GB
- Solid State Drive Configuration
- 1 x 64GB
- Display & Graphics
- Screen Size
- 10.4"
- Display Screen Type
- Active Matrix TFT Color LCD
- Aspect Ratio
- 4:3
- Screen Mode
- XGA
- Screen Resolution
- 1024 x 768
- Color Supported
- 262,144 Colors
- Touchscreen
- Yes
- Graphics Memory Capacity
- 8 MB
- Graphics Memory Technology
- DDR2 SDRAM
- Graphics Memory Accessibility
- Shared
- Network & Communication
- Wireless Connectivity Technology
- Wi-Fi
- Wireless LAN
- Yes
- Wireless LAN Standard
- IEEE 802.11a/b/g/n
- Bluetooth
- Yes
- Bluetooth Standard
- Bluetooth 2.0 + EDR
- Interfaces/Ports
- Total Number of Mini USB Ports
- 1
- Input Devices
- Keyboard Type
- Touchscreen Keyboard
- Pointing Device Type
- Stylus
- Built-in Devices
- Front Camera
- Yes
- Front Camera Resolution
- 2 Megapixel
- Rear Camera
- Yes
- Rear Camera Resolution
- 2 Megapixel
- Focus Modes
- Auto-focus
- Microphone
- Yes
- Speakers
- Yes
- Operating System
- Operating System Platform
- Windows
- Operating System
- Windows XP Professional
- Battery Information
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Battery Capacity
- 3760 mAh
- Maximum Battery Run Time
- 6 Hours
- Power Description
- Input Voltage
- 110 V AC
- 220 V AC
- Maximum Power Supply Wattage
- 63 W
- Physical Characteristics
- Form Factor
- Slate
- Height
- 10.2"
- Width
- 10.2"
- Depth
- 1.7"
- Weight (Approximate)
- 3.31 lb
- Miscellaneous
- Package Contents
- MICA-101 Net-tablet PC
- Lithium Ion Battery
- AC Adapter
- Stylus
- 1 x Warranty Card
- 1 x USB Type A to Mini B Cable
- 3 x Software CD (Drivers and Utility, Recovery OS, Recovery Image)
- Certifications & Standards
- UL
- CE
- CUL
- CCC
- CB60950
- IP54 Certified
- R&TTE (99/5/EC)
- UL2054 and UN38.3
- FCC Part 15 Class B
- Security Features
- RFID Reader
- 1D/2D and UDSI Barcode Scanner
